1, The principle of dc fuse:

The working principle of the fuse is a simple relationship between I2R and time. The greater the current, the shorter the fusing or opening time. The power consumption of the fuse is proportional to the square of the current through the fuse. When the power consumption is too high, the fuse blows. This feature also applies to wire harnesses protected by fuses. If the amount of heat generated exceeds the heat of distribution, the temperature of the fuse will increase, when the temperature rises to the fuse fuse melting point fuse occurs when the fuse is to open the circuit to play a protective role.

2, 1000v fuse Specifications

SGR 1000V DC 1A to 32A DC fuse for solar system

1.Solar system used: DC Fuse block

2.Rared Voltage:DC 250v to 1000V

3:IEC66143-1 & EN61643-II

4,Rated current:1A, 2A, 3A,4A,5A, 6A,8A, 10A, 12A, 15A, 16A, 20A 25A, 30A, 32A to 630A

5.fuse with holder Packaging: 300 set /ctn

6,Shipping: By Express(EMS,DHL,UPS,ARAMEX), By Air or By Sea

7,The Fuse link packing : 3000pcs / carton , packing size is 35*22*23, G/W:21.5KG

8,Fuse holder packing : 300pcs/ carton , packing size 44*39*22, G/W :26KG

9,Can be OEM, the packing can be according customer feel well

3, 1000V Fuse Product Parameter

Type SGR
Fuse size 10 x 38
Poles 1P
Rated voltage DC 1000V
rated current 1,2,3,4,5,6,8,10,12,15,20 up to 630A
short-circuit breaking capacity 33KA
max power attenuation 3.5W
protection grade IP20
connection 2.5-10mm2
operation ambient temperature -30~+70°C
Resistance and damp hot Class 2
elevation ≤ 2000
installation way TH35-7.5/DIN35 Rail installation
RH(relative air humidity) when +20 °C,not exceed 95%;when +40 °C,not exceed 50%
pollution class 3
installation environment the place of no abvious vibrate & impact
installation class
WxHxL W18 x H89 x L90mm
Weight(kg) 0.07

5, The main advantages of fuses

A, Good selectivity Up and down fuse fuse rated current as long as the GB and IEC standards to meet the requirements of the overcurrent ratio of 1.6: 1 requirements, that is, the upper rated fuse current is not less than the subordinate of the value of 1.6 times, as the upper and lower level Selective cut off fault current;

B, Good current limiting characteristics, high breaking capacity;

C, Relatively small size;

D, Cheaper prices.

Structural fratures

Fuse link is made of pure silver(or silver strings),welding low tin and encapsulated in the melt tbe made of high-strength porcelain, the fuse tube filled with high-purity quartz sand chemically processed as the arc medium.Fuse body is connected with contacting terminals by spot welding fuse base suppressed by the resin or plastic casing fitted with contacts and contains the fusion pieces,the connection made by riveting as the support of the appropriate size fuse body parts.This series fuse has a compact and convenient device,use security,beautiful appearance,etc.

6, DC Fuse services :

1.You inquiry related to our products or prices ,  we will be replied in 24hours

2.We have staffs trained and experienced to answer all your enquires in fluent english  3. we have  unique design and some our current models offered for you

4.Protection of you sales area ,ideas of design and all your private information

5.Shipping freight are delivered under your requests

6.Shipping port :Shanghai/Ningbo,mainland china

7.Discounts are offered based on order quantities
